Specification
Camera
|
Image Sensor |
1/2.7” Progressive CMOS |
|
Max Resolution |
8MP(3840×2160） |
|
Night Vision |
30m (98ft) Distance |
|
Focal Length |
2.8/3.6mm F1.6 Fixed Lens |
|
Field of View |
2.8mm: 100°(H), 53°(V), 115°(D) 3.6mm: 89°(H), 45°(V), 105°(D) |
Network
|
Ethernet Port |
1 x 100Mbps Ethernet Port |
|
Imou App |
IOS, Android |
Video & Audio
|
Video Compression |
H.265/H.264 |
|
Video Frame Rate |
Up to 20fps Frame Rate |
|
Focal Length |
8×Digital Zoom |
|
Sound & Light |
Built-in Mic & Speaker |
|
Built-in Spotlights & Red-Blue Warning Lights |
|
|
WDR |
120dB |
Auxiliary Interface
|
Micro SD Card |
Up to 512GB |
|
Reset Button |
YES |
Notice Management
|
Smart Detection |
Motion, Human, Vehicle, Cross Line , Abnormal Sound Alarm |
General
|
Power supply |
PoE DC 12V 1A Power Supply |
|
Power Consumption |
＜4.83W |
|
Working Environment |
-30℃~+60℃， Less Than 95%RH |
|
Dimension(L×W×H) |
109.9 × 109.9 × 93.3mm |
|
Weight |
254g |
|
Certification |
CE, Onvif |
What's in the box?
1×Camera
1×Installation Plate
1×Screw Package
1×Quick Start Guide
1×Waterproof Connector
1×Waterproof Plug
1×Installation Position Map
