Specifications
Camera
|
Image Sensor |
1/2.9” Progressive CMOS |
|
Max Resolution |
4MP(2560×1440) |
|
Night Vision |
Warm Light:30m (98ft) |
|
Focal Length |
3.6mm F1.0 Fixed Lens |
|
Field of View |
81°(H), 45°(V), 95°(D) |
|
Pan & Tilt |
340°Pan & 0~90°Tilt |
Network
|
Ethernet Port |
1 x 100Mbps Ethernet Port |
|
Imou App |
IOS, Android |
|
Other |
Onvif |
Video & Audio
|
Video Compression |
H.265/H.264 |
|
Video Frame Rate |
Up to 25/30 fps Frame Rate |
|
Focal Length |
8×Digital Zoom |
|
Sound & Light |
Two-way Audio |
|
Red-Blue Warning Lights |
Auxiliary Interface
|
Micro SD Card |
Up to 512GB |
|
Built in Mic&Speaker |
YES |
|
Reset Button |
YES |
Notice Management
|
Smart Detection |
Motion, Human, Vehicle Activity Zone, Crossing Line |
General
|
Power supply |
PoE (IEEE 802.3af） DC 12V 1A Power Supply |
|
Power Consumption |
5.4W |
|
Material |
Plastic |
|
Working Environment |
-30℃~+60℃， Less Than 95%RH |
|
Dimension(L×W×H) |
135.2× 182.3×238.5mm (5.32 × 7.18×9.39inch) |
|
Weight |
759g |
|
Certification |
CE |
What’s in the box
Camera×1
Screw Package×1
Quick Start Guide×1
Waterproof Connector×1
Waterproof Plug×1
Installation Position Map×1
Legal and Regulatory Information ×1
