Specification
Camera
|
Image Sensor |
1/3” + 1/3” Progressive CMOS |
|
Max Resolution |
5MP + 5MP (2880×1620） |
|
Night Vision |
56 m ( 184 ft) Distance |
|
Focal Length |
2.8mm F1.6 Fixed Lens 12mm F1.6 Fixed Lens |
|
Field of View |
2.8mm: 94°(H), 52°(V), 111°(D) 12mm: 24°(H), 14°(V), 28°(D) |
|
Pan & Tilt |
0~340°Pan & 0~90°Tilt |
Network
|
Network |
|
|
4G Band |
LTE FDD: 1/3/5/7/8/20/28, LTE TDD: 38/40/41 |
|
Ethernet Port |
1 x 100Mbps Ethernet Port |
|
Imou App |
IOS, Android |
Video & Audio
|
Video Compression |
H.265/H.264 |
|
Video Frame Rate |
Up to 15fps Frame Rate |
|
Focal Length |
12× Mixed Zoom |
|
Sound & Light |
Built-in Mic & Speaker |
|
Built-in Spotlights |
Auxiliary Interface
|
Micro SD Card |
Up to 512GB |
|
Reset Button |
YES |
Notice Management
|
Smart Detection |
Human, Vehicle |
General
|
Power supply |
DC 12V 1A Power Supply |
|
Power Consumption |
＜12W |
|
Working Environment |
-30℃~+50℃， Less Than 95%RH |
|
Dimension(L×W×H) |
238.2 × 147.7 × 182.3mm (9.38× 5.81 × 7.18inch) |
|
Weight |
800g |
|
Certification |
CE, Onvif |
What’s in the box
Camera×1
Screw Package×1
Quick Start Guide×1
Installation Position Map×1
Power Adapter×1
Power Cable×1
