Specification
Camera
Image Sensor：1/3” Progressive CMOS
Max Resolution：3MP(2304×1296)
Night Vision：Warm Light:30m (98ft)
IR:30m (98ft)
Focal Length：3.6mm F1.6 Fixed Lens
Field of View：78°(H), 41°(V), 91°(D)
Pan & Tilt：355°Pan & 0~90°Tilt
Network
Supports Band：
EU:
LTE FDD: Band 1/3/5/7/8/20/28
LTE TDD: Band 38/40/41
AM:
LTE FDD: Band 2/3/4/5/7/8/28/66
LTE TDD: Band 38/40/41
Ethernet Port：1 x 100Mbps Ethernet Port
Imou App：IOS, Android
Other：Onvif
Video & Audio
Video Compression：H.265/H.264
Video Frame Rate：Up to 15 fps Frame Rate
Focal Length：8×Digital Zoom
Sound & Light：Two-way Audio、Red-Blue Warning Lights
Auxiliary Interface
Micro SD Card：Up to 512GB
Built in Mic&Speaker：YES
Reset Button：YES
Notice Management
Smart Detection：
Motion, Human, Vehicle
Activity Zone, Crossing Line
General
Power supply：DC 12V 1A Power Supply
Power Consumption：＜12W
Material：Plastic
Working Environment：-30℃~+50℃，Less Than 95%RH
Dimension：128 × 159× 196 mm
Weight：526g
Certification：CE
What’s in the box
Camera×1
Power Adapter×1
Screw package×1
Quick Start Guide×1
Waterproof Connector×1
Installation Position Map×1
Legal and Regulatory Information ×1
